סרוו AGF SERVO 1/10-1/8 – 45KG

SERVO 45KG

 Main Feature

• Ultra Light Unique Design
• High Performance Standard Digital Servo
• Fast Cooling Heat Sink Case
• Strengthen High Chrome Steel Shaft
• High Efficiency Bruhless Motor
• Programmable Digital Circuit
• Magnetic Sensor Waterproof IP67

 Specification

• Model Name: A81BHMW
• Operating Voltage: 4.8-8.4 V
• Operating speed: 0.115sec/60° @ 6.0V
• Operating speed: 0.100sec/60° @ 7.4V
• Operating speed: 0.085sec/60° @ 8.4V
• Stall Torque: 34 kg-cm (473 oz-in) @ 6.0V
• Stall Torque: 39 kg-cm (542 oz-in) @ 7.4V
• Stall Torque: 45 kg-cm (625 oz-in) @ 8.4V
• Gear: Steel
• Motor: BLS
• Size: 40*20*37.5mm (1.57 x 0.78 x 1.46 in)
• Weight: 83g
• Connector Wire: JR 300 mm
